• FM Remote Control System User Manual Models: PROMAX PROMAX-UA March 2001 Document No. • 2.3.1 Evolution DX2 Keystroke Operations..12 3.0 Model PROMAX-UA Remote Control System (Universal). 13 3.1 Using the Promax-UA Universal Adapter with a Non Rain Master Controller.14 3.2 Installing the PROMAX-UA System..14 3.3 Temporary Connector Installation.. 16 3.4 Disconnecting the PROMAX-UA from a Non-Rain Master Controller. • Figure 6: Complete PROMAX-UA System..13 Figure 7: Relay (such as Rain Master RLY1)..15 Figure 8: PROMAX-UA Installation to a Non-Rain Master Controller.17 Figure 9: Non-Rain Master Controller 24 Volts AC..18 Figure 10: PROMAX-UA Permanent Connection..19 Figure 11: Battery Replacement... • Pro Max Congratulations you have chosen one of the ultimate weapons to use in keeping maintenance costs down and satisfaction high – the Rain Master Pro Max Remote Control System.
Rain Master engineers take great pride in all their work, but they are especially proud of Pro Max. • • Auto-up and auto-down station operation. Flexibility • Can be used with any manufacturers’ 24-volt AC controller (Model PROMAX- UA). • Independent control of the master valve and/or pump. • Single or multi-station capabilities for testing system hydraulics.
• Intelligence • Detects and provides an audible alert against field wiring short circuits (Model PROMAX-UA). • No more tripped circuit breakers or blown fuses during installation checkout. • Receiver has built-in safety default to automatically turn station OFF after 60 minutes. • Rain Master Irrigation Systems Pro Max User’s Manual locations, which are indoors, especially basements, or structures, which are concrete and steel. Nortel Application Builder 5.0 there. It may be possible to remotely locate an external antenna whenever poor Pro Max receiver locations exist. Call Rain Master Technical support for assistance, telephone (805) 527-4498. • Mexico, D.F.
06700 Model PROMAX Remote Control System (Rain Master Only) The PROMAX Pro Max receiver is designed to connect directly to any Rain Master controller by plugging the 9-pin connector from the Pro Max receiver into the front panel remote control jack found ON Rain Master controllers. • Rain Master Irrigation Systems Pro Max User’s Manual PROMAX Parts List Part No. Description PM-XMTR Pro Max Remote radio transmitter PM-RCVR Pro Max Remote receiver PM-SER99 36” remote cable 500055 Pro Max User’s manual PM-CASE Pro Max carrying case. • Rain Master Irrigation Systems Pro Max User’s Manual Upon Receiver Connection Beep Response Description 1 Beep (1/2 sec) Ready Multi-Pro Max receiver mode: • Requires corresponding access code 2 Beeps to enable Pro Max receiver operation. Failed internal diagnostic tests. Contact Rain 3 Beeps Master. • Access codes are required whenever one Pro Max transmitter controls multiple Pro Max Pro Max receivers.
PMRKIT • Permanently mounted Pro Max receiver • Antenna PROMAX-ANT • All interconnecting cables and hardware Note: Operation of a permanent mount Pro Max receiver requires usage of the ACCESS CODE feature key. • Rain Master Irrigation Systems Pro Max User’s Manual Figure 5: Pro Max Transmitter (PM-XMTR) Page 9. • Rain Master Irrigation Systems Pro Max User’s Manual Keystroke Operation The Pro Max keyboard layout is shown in Figure 4. Basic Operation Function Keystrokes Increment to next Station Decrement to next Station Turn On Station 12 Turn Off Station 12 Turn On Master Valve/Pump PUMP Turn Off Master Valve/Pump. • Rain Master Irrigation Systems Pro Max User’s Manual Multiple Stations On (Add Stations) Function Keystrokes Turn On Multiple STATIONS STATIONS STATIONS Stations 1, 2, 6, Turn Station 6 OFF (Station 1, 2 remain) Turn All Stations OFF Turn All Stations OFF and Increment the stations selected From Last Station. • Rain Master Irrigation Systems Pro Max User’s Manual Using Multiple Receivers (Access Code) Function Keystrokes Enable Pro Max Receiver ACCESS #15.
Controller now accepts CODE all remote keys. ACCESS Disable Pro Max Receiver CODE Disable All Pro Max ACCESS CODE Receivers ** This function only works with the following Rain Master controllers: RME Sentar, RME Hawk, Evolution DX2 controllers. • Rain Master Irrigation Systems Pro Max User’s Manual Model PROMAX-UA Remote Control System (Universal) The PROMAX-UA Universal Adapter Model offers the capability to connect to virtually any controller, regardless of manufacturer.
This system consists of: Figure 6: Complete PROMAX-UA System PROMAX-UA Parts List Part No. • In cases where the controller does not provide the required 24 Volts AC, a step-down transformer is employed to convert standard 117 Volts AC or 220 Volts AC to 24 Volts Using the Promax-UA Universal Adapter with a Non Rain Master Controller The controller serves only two purposes when using the Universal Adapter.
